Kingsman Serene Marquis Collection
Serene
ZERO CLEARANCE DIRECT VENT GAS FIREPLACE
| Model | ZCVRB47N/NE MQZCVRB47NE2† |
ZCVRB47LP/LPE MQZCVRB47LPE2† |
| Fuel | Natural | Propane |
| Gas Control | Millivolt / IPI | Millivolt / IPI |
| Input Max. | 24,500 BTU | 24,500 BTU |
| Input Min. | 16,500 BTU | 20,500 BTU |
| FE (P.4.1-15) | 55.26% / 57.31% | 55.01% / 57.10% |
| Glass Size | 40 5/8” W x 13 7/8” H | |
| Venting | 4/7" Flex or 4 x 6 5/8" Hard Pipe |
STANDARD FEATURES
- Hi/Low Millivolt or IPI valve system will operate during power failures
- Bronze Glass
- Mobile Home, Bedroom and Bed Sitting Room approved
- Proflame II† Models include remote control – features flame, fan, thermostat, smart thermostat and LED lights
- Safety Screen Barrier
OPTIONAL FEATURES
Surround: Black or Stainless Steel
Fan Kit: Heat activated with variable speed control
Universal Light Kit: Two Lamps (accent lighting)
Wall Mount Thermostat: Standard on/off or Programmable 5 day (weekday) and 2 day (weekend)
Driftwood Log Sets: Three Piece Driftwood Set (MQ46D), Four Piece Driftwood with Four Rocks (MQRBD1), Three Piece Driftwood Log Set (MQRBD4) or Five Piece Driftwood Set (MQRBD3)
Media Options: Contemporary Rocks, Decorative Stones, Decorative Ember Glass (Glacier Ice, Cobalt Blue, Black, Bronze, White), Ember Chunks or Multi-Colored Cannonballs
Liners: Porcelain Reflective or Fluted Brick
Remote Controls: Thermostat on/off, Thermostat on/off modulating, Thermostat on/off modulating, fan control and lights
Enclosure Grill (unfinished):
Front – V46EG 46 9/16” W x 2 1/2” H
Side – VL48EGS 16 3/16" W x 7 1/4" H
VENTED CHASE OPTION
The chase of the appliance may be vented to achieve Cool Touch Walls or reduced Mantel Clearances. The following options are available to vent the chase:
- The top of the chase can be left open.
- A grill can be installed on the front of the chase.
- If the chase bumps out into the room, side grills can be installed on each side of the chase.
