Realistic Appearance
Hand-painted and realistic logs for a traditional hand- built fire appearance
Triple Burner System
Turbo boosts” the heating power to increase the already impressive 30,000 BTU’s to 44,000 BTU’s and provides a wood fire effect that delivers the benefit of a heat activated variable speed blower system
Electronic Ignition
Fuel-saving electronic ignition with battery back-up so you can stay problem-free when power-free
FEATURES
- 357 sq. in. viewing area
- 100% SAFE GUARD™ automatic gas shut off for your peace of mind
- Includes heat activated variable speed blower
- Easy clean hinged door
- Exclusive PHAZER™ log set with traditional glowing charcoal embers
- Metallic black accent bar, ornamental inset and trivet are standard features
- Door available in metallic black or satin chrome plated finishes
- Optional remote
- Optional Natural Draft Adapter Kit allowing installation into existing chimneys
SPECIFICATIONS
CDVS500
| BTU’s (Input) | 44,000 |
| Venting | Top 4” / 7” |
| Glass Type | Ceramic |
| Mobile Home Certified | Yes |
| OVERALL UNIT | |||
|---|---|---|---|
| A | B | C | D |
| 21” | 30 3/4” | 28 1/4” | 21 5/8” |
| GLASS VIEWING AREA | |
|---|---|
| Height | 13 3/8” |
| Width | 25 3/4” |
40,000 BTU when converted to propane.
| MAXIMUM CLEARANCES | |
|---|---|
| Corner | 1” |
| Rear | 2” |
| Side | 7” |
Finishing flange depth (The finishing flange defines the perimeter of the fireplace opening). Framing or finishing materials must NEVER encroach inside the finishing flange.
