Advanced Burner System
Produces realistic unique flames for a warm, inviting glow
Variable Heat Range
Control the exact amount of heat needed with up to 30,000 BTU’s aided by a heat activated variable blower system that is included
Electronic Ignition
Fuel-saving electronic ignition with battery back-up so you can stay problem-free when power-free
FEATURES
- 280 sq. in. viewing area
- 100% SAFE GUARD™ automatic gas shut off for your peace of mind
- Easy clean hinged door
- Exclusive PHAZER™ log set with traditional glowing charcoal embers
- Metallic black accent bar, ornamental inset and trivet are standard features
- Door available in metallic black or satin chrome plated finishes
- Optional remote
- Optional Natural Draft Adapter Kit
SPECIFICATIONS
CDVS280
| BTU’s (Input) | 30,000 |
| Venting | Top 4” / 7” |
| Glass Type | Ceramic |
| Mobile Home Certified | Yes |
| OVERALL UNIT | |||
|---|---|---|---|
| A | B | C | D |
| 17 3/4” | 26 3/4” | 22 1/2” | 18 1/2” |
| GLASS VIEWING AREA | |
|---|---|
| Height | 11 3/8” |
| Width | 24 1/2” |
| MAXIMUM CLEARANCES | |
|---|---|
| Corner | 1” |
| Rear | 2” |
| Side | 7” |
*Finishing flange depth (The finishing flange defines the perimeter of the fireplace opening). Framing or finishing materials must NEVER encroach inside the finishing flange
